Tankii K-TYPE Thermocouple Wire With Magnet Block Used For Surface Temperature Measurement
Magnetic thermocouple sensor
The Magnetic switchable device can quickly contact the surface
Reusable
A magnetic probe suitable for long-term temperature measurement on surfaces with contact pressure.
It takes 10 seconds to reach the surface temperature.
Tankii thermocouple can have a miniature k-type connector (as per your request) that will work with digital K-type thermometers of many manufacturers.
Tankii k type thermocouple can be made from very thin k-type sensor wire, the thermocouple wire diameter is approximately AWG 29 (0.011 inch or 0.28 mm), this will give you very quick temperature readings.
This kind of probe can used to measure air or gas temperatures, it can be attached to pipes or embedded into objects you want to measure. It also can be used in non-corrosive liquids, such as water that does not have much salt or acid in it.
The conditions of measurement determine the type of tankii thermocouple wire and insulation to be used.
Temperature range, environment, insulation requirements, response, and service life should be considered.
Tankii K-TYPE Thermocouple Wire With Magnet Block Used For Surface Temperature Measurement
Detailed Description
| Conductor Name | Type | Applicable thermocouple type |
| Cu-Constantan0.6 | SC or RC | S or R |
| Iron-constantan22 Copper-Constantan40 Chromel-Ni(Alumel) | KCA KCB KX | K |
| Iron-constantan18 NiCr14Si-NiSi4Mg | NC NX | N |
| NiCr10-Constantan45 | EX | E |
| Iron-Constantan 45 | JX | J |
| Copper-Constantan 45 | TX | T |
Tankii K-TYPE Thermocouple Wire With Magnet Block Used For Surface Temperature Measurement
The standards we can meet for thermocouple :
| ASTM | (American Society for Testing and Materials) E 230 |
| ANSI | (American National Standard Institute) MC 96.1 |
| IEC | (European Standard by the International Electrotechnical Commission 584)-1/2/3 |
| DIN | (Deutsche Industrie Normen) EN 60584 -1/2 |
| BS | (British Standards) 4937.1041, EN 60584 - 1/2 |
| NF | (Norme Française) EN 60584 -1/2 - NFC 42323 - NFC 42324 |
| JIS | (Japanese Industrial Standards) C 1602 - C 1610 |
| GOST | (Unification of the Russian Specifications) 3044 |
Packaging & Delivery
| Packaging Details | Roll with plastic film wrapped and carton package |
| Delivery Detail | Shipped in 7 ~15 days after payment |
Cable type thermocouple sensor:
FAQ:
1. Payment ways?
T/T, PAYPAL, WESTUNION.
2. When will you arrange the production?
In 12 hours since we get your payment.
3. Product certifications?
MTC , ISO9001, ROHS , SGS as customers' request
4. What kind of informations shall I give you regarding the shipping?
Company name, Recipients, Correct Address, telephone, zip code.
5. What is your warranty ?
For most of our products, the warranty will be 12 months.
6. When will I get a solution for defective products?
Within 48 hours (on working days )
7. What is your shipping way?
DHL, FEDEX, UPS, TNT, EMS, CHINA POST AIR, SEA FREIGHT and AIR FREIGHT!
8. What is your shipping time?
For General Orders, the shipping time will be 7 workdays.
ANSI Red And Blue T Type Thermocouple Cable With PVC Insulation And Blue Jacket
Welcome to call me or email to me for more info on thermocouple wire, thermocouple cable , RTD cable and thermocouple related products.
