Round 0Cr27Al7Mo2 FeCrAl Alloy For High Temperature Industrial Furnace

Name: Round 0Cr27Al7Mo2 FeCrAl Alloy For High Temperature Industrial Furnace
Brand: TANKII
Price: 5 USD

Wholesale Round 0Cr27Al7Mo2 FeCrAl Alloy For High Temperature Industrial Furnace from china suppliers

Brand Name : TANKII

Model Number : 0Cr27Al7Mo2

Certification : DIN, ASTM, JIS

Place of Origin : Jiangsu

MOQ : 10KG

Price : 5-25USD/KG

Payment Terms : T/T, L/C

Supply Ability : 50 tons per month

Delivery Time : 5-10 work days

Packaging Details : spool ,coil, or as clients' requirement

Application : furnace heating wire

Shape : round wire

Material : Fecral

Chemical composition : Fe Cr Al

Dimensions : 0.05-12mm

Surface : acid/oxidized

Density : 7.1

Color : oxidized

Melting point : 1500°

Feature : high corr

Condition : soft/hard

Resistivity : 1.53

Tensile strength : 680-830N/mm²

Product name : Resistance wire Fecral alloy wre 0Cr27Al7Mo2

Size : 0.02-10mm

Surface treatment : bright oxidation

Contact Now

Product discription

TANKII FeCrAl Alloy 0Cr27Al7Mo2 for high temperature industrial furnace


FeCrAl alloy is high resistance and electrical heating alloy. FeCrAl alloy can reach process temperatures of 2192 t0 2282oF, corresponding to a resistance temperature of 2372 oF. In order to improve anti-oxidation ability and increase working life, we usually put addition of rare earths in the alloy such as La + Ce, Yttium, Hafnium, Zirconium, etc.
0Cr27Al7Mo2 is normally used in electrical furnace, glass top hobs, quartz tube heaters, resistors, catalytic coverter, hearting element and etc.

0Cr27Al7Mo2 is one kind of normal material of Fe-Cr-Al alloy.
 It has the characteristic of high resistivity,low temperature resistance coefficient, high operating temperature, good anti-oxidation and anti-corrosion under high temperature.It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive,
 military and other industries producing heating elements and resistance elements.

 Size dimension range:
 Wire: 0.01-10mm
 Ribbons: 0.05*0.2-2.0*6.0mm
 Strip: 0.05*5.0-5.0*250mm
 Bar:10-50mm

Specification

Grade	Highest temperature	Resistivity	Melting point	Tensile strength	Elongation
0Cr21Al4	1100℃	1.23±0.06μΩ.m	1500℃	750	≥12
0Cr25Al5	1250℃	1.42±0.07μΩ.m	1500℃	750	≥12
0Cr23Al5	1300℃	1.35±0.06μΩ.m	1500℃	750	≥12
0Cr21Al6Nb	1350℃	1.43±0.07μΩ.m	1510℃	750	≥12
0Cr27Al7Mo2	1400℃	1.53±0.07μΩ.m	1520℃	750	≥10
KSC	1350℃	1.44±0.05μΩ.m	1510℃	750	≥16
Cr20Ni80	1200℃	1.09±0.05μΩ.m	1400℃	750	≥20
Cr15Ni60	1150℃	1.12±0.05μΩ.m	1390℃	750	≥20
Cr20Ni35	1100℃	1.04±0.05μΩ.m	1390℃	750	≥20
Cr20Ni30	1100℃	1.04±0.05μΩ.m	1390℃	750	≥20

Round 0Cr27Al7Mo2 FeCrAl Alloy For High Temperature Industrial Furnace

Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.

Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.

Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
